| Size/Weight |
| Dimensions |
Width |
1,310 mm (51-9/16") |
1,089 mm (42-7/8") |
882 mm (34-3/4") |
| Height |
152 mm (5-15/16") |
117 mm (4-5/8") |
117 mm (4-5/8") |
| Depth |
391 mm (15-3/8") |
347 mm (13-11/16") |
347 mm (13-11/16") |
| Weight |
Weight |
13.6 kg (29 lb, 15 oz) |
7.6 kg (16 lb, 12 oz) |
6.6 kg (14 lb, 9 oz) |
| Control Interface |
| Keyboard |
Number of Keys |
88 |
76 |
61 |
| Type |
GHS Keyboard |
Semi-weighted FSB Keyboard |
Semi-weighted FSB Keyboard |
| Initial Touch |
Yes |
Yes |
Yes |
| Aftertouch |
No |
No |
No |
| Tone generator |
| Tone Generator |
Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise |
Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise |
Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise |
| Maximum Polyphony |
AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) |
AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) |
AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.) |
| Multi Timbral Capacity |
16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part |
16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part |
16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part |
| Wave |
Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB |
Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB |
Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB |
| Performance |
3,427 |
3,427 |
3,427 |
| Filter |
18 types |
18 types |
18 types |
| Effects |
Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) |
Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) |
Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) |
| Performance Recorder |
| Note Capacity |
1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) |
1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) |
1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) |
| Note Resolution |
480 ppq (parts per quarter note) |
480 ppq (parts per quarter note) |
480 ppq (parts per quarter note) |
| Tempo (BPM) |
5 – 300 |
5 – 300 |
5 – 300 |
| Sequence formats |
MONTAGE M/MODX M original format, SMF formats 0, 1 |
MONTAGE M/MODX M original format, SMF formats 0, 1 |
MONTAGE M/MODX M original format, SMF formats 0, 1 |
| Arpeggio |
Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types |
Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types |
Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types |
| Sequencer |
| Patterns |
128 patterns |
128 patterns |
128 patterns |
| Pattern tracks |
16 Sequence tracks |
16 Sequence tracks |
16 Sequence tracks |
| Pattern Recording type |
Real time replace, Real time overdub |
Real time replace, Real time overdub |
Real time replace, Real time overdub |
| Songs |
128 songs |
128 songs |
128 songs |
| Song tracks |
16 Sequence tracks, Tempo track, Scene track |
16 Sequence tracks, Tempo track, Scene track |
16 Sequence tracks, Tempo track, Scene track |
| Song recording type |
Real time replace, Real time overdub, Real time punch in/out |
Real time replace, Real time overdub, Real time punch in/out |
Real time replace, Real time overdub, Real time punch in/out |
| Functions |
| USB audio interface |
[Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) |
[Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) |
[Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel) |
| Other |
| Controllers |
Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch |
Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch |
Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch |
| Display |
7" TFT Color Wide VGA LCD touch screen |
7" TFT Color Wide VGA LCD touch screen |
7" TFT Color Wide VGA LCD touch screen |
| Connectors |
USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
| Power Consumption |
19 W (When using PA-300C AC adaptor) |
19 W (When using PA-300C AC adaptor) |
19 W (When using PA-300C AC adaptor) |
| Accessories |
AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card |
AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card |
AC adaptor: PA-300C, Quick guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M/MODX M Download Information, About downloading manuals, Welcome card |
| Live Sets |
Preset: 256, User: 2,048 |
Preset: 256, User: 2,048 |
Preset: 256, User: 2,048 |
